SATIMO Anechoic chamber

SATIMO Microwave anechoic chamber can provide all kinds of passive and active testing.

•Measurement includes：Gain, Efficiency, Radiation Power, BER, sensitivity…

•TRP/TIS Measurements conform to CTIA standards.

•Free space & Talk State Testing Ability.

•The test frequency range includes： 400Mhz to 6GHZ

ETS-AMS 8500 Anechoic chamber

 4*4*7 m ETS-AMS 8500 Microwave anechoic chamber can provide all kinds of passive and active testing.

• Include Gain, Efficiency, Radiation Power, BER, sensitivity…

• TRP/TIS Measurements conform to CTIA standards.

• Free space & Talk State Testing Ability.

• The test frequency range includes： 400Mhz to 6GHZ

NFC Test Equipment	SAR Test equipment

EDX2800 RoHS Analytical Detector

It can simultaneously and accurately detect the elements stipulated or related by EU RoHS Directive in 60-300S: lead (Pb), mercury (Hg), cadmium (Cd), chromium (Cr), bromine (Br).

Dimension Testing Projector（No.:JT-300A)

•Antenna Dimension Tolerance Requirements： (+0，-0.15mm)

•Standard Tolerance of Finished Product Dimension Testing Industry

2.5D Image tester

Measurement - Measurable dimensions of geometric figures on a plane (angle, length, diameter, radius, distance from point to line, eccentricity of circle, distance between two circles, etc.)
Graphic Output - It can be output to AutoCAD as a standard engineering drawing according to the shape of the actual workpiece in the real-time image.

Environmental simulation tester

Test description：

Testing antenna products for high and low temperature   Resilience to shocks.

Test conditions：

Salt spray tester

Testing instructions: Check the environmental ability of metal shrapnel to resist salt spray corrosion.
Test conditions: 1. Salt water test: the laboratory temperature is set at 35 saturated air barrel temperature is set at 47 2. Corrosion test:
